Lifepo4 Lithium Ion Battery System For Home Solar Power Long Lifespan

Product Details

Place of Origin: Zhejiang, China

Brand Name: GBS

Certification: CE,TUV,UL,IEC,ISO9001,ISO14001,OHSAS18001

Model Number: GBS-LFP100Ah-A

Payment & Shipping Terms

Minimum Order Quantity: 1PC

Price: Negotiable

Packaging Details: Standard Packaging

Delivery Time: 7 work days

Payment Terms: T/T

Get Best Price
Contact Now
Specifications
High Light:

lithium ion battery for solar storage

,

lithium ion battery pack for solar

Material:
LiFePO4
Dimension:
126x65x243mm
Warranty:
2 Years
Application::
Solar Systems, UPS , Lighting, Sound Systems, Medical Device, Golf Trolleys,
Material:
LiFePO4
Dimension:
126x65x243mm
Warranty:
2 Years
Application::
Solar Systems, UPS , Lighting, Sound Systems, Medical Device, Golf Trolleys,
Description
Lifepo4 Lithium Ion Battery System For Home Solar Power Long Lifespan

Lifepo4 Lithium Ion Battery System For Home Solar Power Long Lifespan



Applications:



Electric vehicle

Golf cart

Electric motorcycle

Electric boat

Electric forklift

Telecommunication

Distributed Grid Energy Storage system

Mining equipment

Solar energy storage system

Marine

Backup power

Household energy storage system

Specifications



Good performance under high and low temperature;



Good safety performance;



Good cycle life time;



No pollution during manufacture.





Certifications:

Lifepo4 Lithium Ion Battery System For Home Solar Power Long Lifespan 0

Lifepo4 Lithium Ion Battery System For Home Solar Power Long Lifespan 1





Applications:

Electric vehicle
Golf cart
Electric motorcycle
Electric boat
Electric forklift
Telecommunication
Distributed Grid Energy Storage system
Mining equipment
Solar energy storage system
Marine
Backup power
Household energy storage system





Cell Dimension:

Lifepo4 Lithium Ion Battery System For Home Solar Power Long Lifespan 2





Specification of battery cell

GBS-LFP100Ah-A

Item

Specification

Remark

4.1 Rated capacity

100Ah

0.33C rate discharge capacity

4.2 Minimum capacity

100Ah

4.3 Internal impedance

0.6



4.4 Nominal voltage

3.2V



4.5 Cell weight

2.8±0.1KG



4.6 Standard discharge conditions

Constant current

50A



End-of-charge voltage

2.8V



4.7 Standard charge

method

Constant current

25A



Charge voltage

3.65V



4.8 Fast charge method

Constant current

100A



Charge voltage

3.65V



4.9 Max continuous discharge current

300A



4.10 Pulse discharge current at 10 sec

1000A



4.11 Self-discharge

1% per month



4.12 Cycle life(0.5C)

3000 cycles

80% DOD(25±2)

4.13 Operating temperature

Charging ambient

temperature

0~65



Discharging ambient

temperature

-20~65℃



Storage temperature

-20~65℃



4.14 Appearance

Without break, distortion, contamination, leakage.







Basic Performance

(1) Output with high efficiency: Standard discharge current is 0.3C-0.8C, instant impulse discharge current is 10C for10 seconds.

(2) Good performance under high temperature, it could work under 65°C temperature.The battery structure

is safe and good.

(3) Good performance under low temperature.discharge capacity decreases to over 90% under 0°C and dischargecapacity decreases to over 70% under -20°C.

(4) Good safety performance:When the pressure inside the battery is too large, the one-way safety valve will release gas and heat to make sure battery perform well. When the internal pressure reaches a certain level, the valve will be open immediately which can protect the battery from burning and explosion.

(5) Good cycle life time, the discharge capacity is still over 80% after 3000 cycle times of single cell(80%DOD).

(6) It can fast charging. It could be charged to 80% within 0.5h and charged full with 2-3h.

(7) No pollution during manufacture and usage.





Requirement for safety assurance

For the sake of safety assurance, please discuss the equipment design, its system and protection circuit of Lithium-ion cell advance. And consult about the high rate current, rapid charge and special application in the same way.
