3.2v Lithium Ion Solar Energy Storage Batteries , Lifepo4 Battery For Solar Storage

Minimum Order Quantity : 1PC Price : Negotiable
Packaging Details : Standard Packaging Delivery Time : 7 work days
Payment Terms : T/T
Place of Origin: Zhiejiang, China Brand Name: GBS
Certification: CE,TUV,UL,IEC,ISO9001,ISO14001,OHSAS18001 Model Number: GBS-LFP100Ah-A

Detail Information

Material: LiFePO4 Dimension: 126x65x243mm
Warranty: 2 Years Cycle Life:: 2000 Times
Use: Solar Energy Storage System Marine Backup Power Voltage: 3.2v
High Light:

lithium ion solar battery

,

lithium ion battery for solar storage

Product Description

3.2v lithium ion battery for solar energy



Specifications



Good performance under high and low temperature;



Good safety performance;



Good cycle life time;



No pollution during manufacture.





Applications:

Electric vehicle
Golf cart
Electric motorcycle
Electric boat
Electric forklift
Telecommunication
Distributed Grid Energy Storage system
Mining equipment
Solar energy storage system
Marine
Backup power
Household energy storage system





Certifications:



3.2v Lithium Ion Solar Energy Storage Batteries , Lifepo4 Battery For Solar Storage 0

3.2v Lithium Ion Solar Energy Storage Batteries , Lifepo4 Battery For Solar Storage 1





Cell Dimension



3.2v Lithium Ion Solar Energy Storage Batteries , Lifepo4 Battery For Solar Storage 2





Specification of battery cell

GBS-LFP100Ah-A



Item

Specification

Remark

4.1 Rated capacity

100Ah

0.33C rate discharge capacity

4.2 Minimum capacity

100Ah

4.3 Internal impedance

0.6



4.4 Nominal voltage

3.2V



4.5 Cell weight

2.8±0.1KG



4.6 Standard discharge conditions

Constant current

50A



End-of-charge voltage

2.8V



4.7 Standard charge

method

Constant current

25A



Charge voltage

3.65V



4.8 Fast charge method

Constant current

100A



Charge voltage

3.65V



4.9 Max continuous discharge current

300A



4.10 Pulse discharge current at 10 sec

1000A



4.11 Self-discharge

1% per month



4.12 Cycle life(0.5C)

3000 cycles

80% DOD(25±2)

4.13 Operating temperature

Charging ambient

temperature

0~65



Discharging ambient

temperature

-20~65℃



Storage temperature

-20~65℃



4.14 Appearance

Without break, distortion, contamination, leakage.









Basic Performance

(1) Output with high efficiency: Standard discharge current is 0.3C-0.8C, instant impulse discharge current

is 10C for 10 seconds.

(2) Good performance under high temperature, it could work under 65°C temperature.The battery structure

is safe and good.

(3) Good performance under low temperature.discharge capacity decreases to over 90% under 0°C and discharge capacity decreases to over 70% under -20°C.

(4) Good safety performance:When the pressure inside the battery is too large, the one-way safety valve

will release gas and heat to make sure battery perform well. When the internal pressure reaches a certain level, the valve will be open immediately which can protect the battery from burning and explosion.

(5) Good cycle life time, the discharge capacity is still over 80% after 3000 cycle times of single cell(80%DOD).

(6) It can fast charging. It could be charged to 80% within 0.5h and charged full with 2-3h.

(7) No pollution during manufacture and usage.





Requirement for safety assurance

For the sake of safety assurance, please discuss the equipment design, its system and protection circuit

of Lithium-ion cell advance. And consult about the high rate current, rapid charge and special application

in the same way.
