Product Details
Place of Origin: China
Brand Name: GBS
Certification: CE,UL,IEC62619,TUV,ISO9001,ISO14001,OHSAS18001
Model Number: GBS-12V20Ah-A
Payment & Shipping Terms
Minimum Order Quantity: 4PCS
Price: USD64
Packaging Details: Special carton for dangerous goods
Delivery Time: 7 WORKDAYS
Payment Terms: L/C, T/T
Supply Ability: 3000000PCS PER YEAR
Type: |
LiFePo4 |
Warranty: |
24 Months |
Nominal Capacity: |
20ah |
Nominal Voltage: |
12V |
Cycle Life: |
3000 Times |
Type: |
LiFePo4 |
Warranty: |
24 Months |
Nominal Capacity: |
20ah |
Nominal Voltage: |
12V |
Cycle Life: |
3000 Times |
Length : 180mm
Width : 74mm
Height : 154mm
| Item | Specification | Remark | |
| Rated capacity | 20Ah | 0.2C rate discharge capacity | |
| Minimum capacity | 20Ah | ||
| Nominal voltage | 12.8V | ||
| Cell weight | 3.0kg±0.1kg | ||
|
Standard discharge conditions |
Constant current | 10A | |
| End-of-discharge voltage | 11.2V | ||
| Standard charge method | Constant current | 5A | |
| Charge voltage | 14.6V | ||
| Fast charge method | Constant current | 20A | |
| Charge voltage | 14.6V | ||
| Max continuous discharge current | 60A | ||
| Cycle life | 3000 cycles | 80% DOD | |
| Operating temperature |
Charging ambient temperature |
0~45°C | |
|
Discharging ambient temperature |
-20~65°C | ||
| Storage temperature | 0~45°C | ||
| Appearance |
Without break, distortion, contamination, leakage. |
||
FAQ:
Trial order is 3-7 work days,formal order 7-20 work days.
Yes, but it is charged.
Yes.
Yes, we are the manufacturer of GBS LiFePO4 battery.
Normally by sea. Shipping time depends on destination port. But we can also make shipment by UPS and Fedex for trial order.
2 years.
We always supply High-Quality products & High-Stand service to our clients.
