Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells

Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells

High Discharge Lifepo4 Battery Cells

3.2v 20000mah Lifepo4 Battery Cells

3.2v 20000mah Lithium Iron Cell

Place of Origin:

China

Brand Name:

GBS

Certification:

CE,UL,IEC62619,TUV,ISO9001,ISO14001,OHSAS18001

Model Number:

GBS-12V20Ah-A

Contact Us

Request A Quote
Product Details
Type:
LiFePo4
Warranty:
24 Months
Nominal Capacity:
20ah
Nominal Voltage:
12V
Cycle Life:
3000 Times
Payment & Shipping Terms
Minimum Order Quantity
4PCS
Price
USD64
Packaging Details
Special carton for dangerous goods
Delivery Time
7 WORKDAYS
Payment Terms
L/C, T/T
Supply Ability
3000000PCS PER YEAR
Product Description

Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells 0



Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells 1





Length : 180mm

Width :   74mm

Height : 154mm





Item Specification Remark
Rated capacity 20Ah 0.2C rate discharge capacity
Minimum capacity 20Ah
Nominal voltage 12.8V
Cell weight 3.0kg±0.1kg

Standard discharge

conditions

Constant current 10A
End-of-discharge voltage 11.2V
Standard charge method Constant current 5A
Charge voltage 14.6V
Fast charge method Constant current 20A
Charge voltage 14.6V
Max continuous discharge current 60A
Cycle life 3000 cycles 80% DOD
Operating temperature

Charging ambient

temperature

0~45°C

Discharging ambient

temperature

-20~65°C
Storage temperature 0~45°C
Appearance

Without break,

distortion, contamination,

leakage.







Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells 2

Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells 3



Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells 4

Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells 5

Original Li Ion 3.2v 20000mah High Discharge Lifepo4 Battery Cells 6



FAQ:



  • When will you ship the products when payment is done?

Trial order is 3-7 work days,formal order 7-20 work days.



  • Is the sample available?

Yes, but it is charged.



  • Can I get a lower price if I order large quantities?

Yes.



  • Are you a factory?

Yes, we are the manufacturer of GBS LiFePO4 battery.



  • How you shipping the goods and how long it will take?

Normally by sea. Shipping time depends on destination port. But we can also make shipment by UPS and Fedex for trial order.



  • What is warranty?

2 years.
