    High Safety 12V 20Ah 300W Lithium Ion Battery For Golf Buggy / Golf Carts

    Product Details:

    Place of Origin: CHINA
    Brand Name: GBS
    Certification: CE, UL, IEC, TUV,PONY,MA,ISO9001, ISO14001, OHSAS18001
    Model Number: GBS-LFP20Ah

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PCS
    Price: Negotiable
    Packaging Details: special cartion for dangerous goods
    Delivery Time: 3-10 DAYS
    Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability: 1800000 PCS PER YEAR
    Get Best Price Contact Now

    Detail Information

    Application: Electric Bike,scooter, HEV, EV, Solar Energy, Teleom Warranty: 38 Months
    Life Cycle: More Than 2000 Cycles Payment: TT,LC
    Material:: LiFePO4 Feature: High Energy Density.
    High Light:

    lithium golf cart batteries

    ,

    lithium ion battery for golf trolley

    Product Description

    High Safety 12V 20Ah 300W Lithium Ion Battery For Golf Buggy / Golf Carts

    12V 20Ah 300W Lithium Golf Power Battery for Golf Carts Golf Trolley Electric TrolleyGBS-LFP20Ah



    Feature:

    1. Ultra thin
    2. No Pollution
    3. Longer life cycle
    4. Ultra light weight
    5. High energy density
    6. High powerdensity
    7. Higher safety performance
    8. Special polymer separator using
    9. Most advanced technology battery
    10. The electrolyte of the cell is completely gelatinized




    Item Specification Remark
    Rated capacity 20Ah 0.2C rate discharge capacity
    Minimum capacity 20Ah
    Internal impedance ≤10mΩ
    Nominal voltage 12V
    Cell weight 3.0kg±100g

    Standard discharge

    conditions

    Constant current 10A
    End-of-discharge voltage 11.2V
    Standard charge method Constant current 10A
    Charge voltage 14.2V
    Fast charge method Constant current 20A
    Charge voltage 14.2V
    Max continuous discharge current 60A
    Cycle life 2000 cycles 80% DOD
    Operating temperature

    Charging ambient

    temperature

    0~65°C

    Discharging ambient

    temperature

    -20~65°C
    Storage temperature -20~65°C
    Appearance

    Without break,

    distortion, contamination,

    leakage.







    Item Description Dimensions

    L Length 178mm

    W Width 75mm

    H Height 165mm



    High Safety 12V 20Ah 300W Lithium Ion Battery For Golf Buggy / Golf Carts 0





    Basic Performance



    (1) Output with high efficiency: Standard discharge current is 0.3C-0.8C, instant impulse discharge current is 10C for 10 seconds.



    (2) Good performance under high temperature, it could work under 65°C temperature.The battery structure is safe and good.



    (3) Good performance under low temperature.discharge capacity decreases to over 78% under 0°C and discharge capacity decreases to over 70% under -20°C.



    (4) Good safety performance:When the pressure inside the battery is too large, the one-way safety valve will release gas and heat to make sure battery perform well. When the internal pressure reaches a certain level, the valve will be open immediately which can protect the battery from burning and explosion.



    (5) Good cycle life time, the discharge capacity is still over 80% after 2000 cycle times of single cell(80%DOD).



    (6) It can fast charging. It could be charged to 80% within 20 minutes and charged full with 2-3h.



    (7) Low cost.



    (8) No pollution during manufacture and usage.



    Matters needing attention



    (1) Please check if spare parts are completed when open the package and read the operation manual carefully.



    (2) Do not make the battery Short Circuit,do not over charge and discharge.



    (3) Please charge the new battery to full capacity before discharge for the first use.



    (4) The battery pack is fixed with plate and strip before delivery, do not disassemble the plate and strip when using the battery.



    (5) Checking the voltage of battery, normally it is 12.8V-13.2V.



    (6) Fix BMS for battery pack and protect single cell to avoid over charge and over-discharge.



    (7) Rivet or screw is used for battery connector.



    (8) Please use copper part to connect battery packs and fix with hydraulic pressure plier. We could also provide the relevantconnection which fixed with screws.



    (9) The charger used should be approved by our company in order to match with our lithium batteries.



    (10) It will shorten battery cycle lifetime and damage battery due to overcharge and over-discharge if not do according to the above . It won’t be within our company warranty.



    Requirement for safety assurance



    For the sake of safety assurance, please discuss the equipment design, its system and protection circuit of Lithium-ion cell advance. And consult about the high rate current, rapid charge and special application in the same way.
