PP Shell Lifepo4 Prismatic Cells , Lithium Iron Phosphate Battery Eco Friendly

PP Shell Lifepo4 Prismatic Cells , Lithium Iron Phosphate Battery Eco Friendly

lithium iron phosphate cells

lithium iron phosphate prismatic cells

Place of Origin:

Zhejiang, China

Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
2 Years
Wheelchair, Mobility Scooter, Solar, Golf Cart And So On
Long Standby Time
Protection Function::
Overcharge ,Overdischarge, Over Current Protection
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Standard Packaging
Delivery Time
7 work days
Payment Terms
Product Description

prismatic pp shell lifepo4 batteries



Good performance under high and low temperature;

Good safety performance;

Good cycle life time;

No pollution during manufacture.




Our characteristics:


Intelligent Production Line


Automatic Warehousing System


Clear Visual Management


Standardized Management Certifications


Research and Development Innovation


Research and Development Capability




Cell Dimension:


PP Shell Lifepo4 Prismatic Cells , Lithium Iron Phosphate Battery Eco Friendly 0




Specification of battery cell


Item Specification Remark
4.1 Rated capacity 200Ah 0.33C rate discharge capacity
4.2 Minimum capacity 200Ah
4.3 Internal impedance ≤0.6mΩ
4.4 Nominal voltage 3.2V
4.5 Cell weight 6.5±0.1KG
4.6 Standard discharge conditions Constant current 100A
End-of-charge voltage 2.8V

4.7 Standard charge


Constant current 50A
Charge voltage 3.65V
4.8 Fast charge method Constant current 200A
Charge voltage 3.65V
4.9 Max continuous discharge current 600A
4.10 Pulse discharge current at 10 sec 2000A
4.11 Self-discharge ≤3% per month
4.12 Cycle life(0.5C) 3000 cycles 80% DOD(25±2℃)
4.13 Operating temperature

Charging ambient



Discharging ambient


Storage temperature -20~65℃
4.14 Appearance Without break, distortion, contamination, leakage.





Electric vehicle
Golf cart
Electric motorcycle
Electric boat
Electric forklift
Distributed Grid Energy Storage system
Mining equipment
Solar energy storage system
Backup power
Household energy storage system




Basic Performance


(1) Output with high efficiency: Standard discharge current is 0.3C-0.8C, instant impulse discharge current is 10C for 10 seconds.

(2) Good performance under high temperature, it could work under 65°C temperature.The battery structure is safe and good.

(3) Good performance under low temperature.discharge capacity decreases to over 90% under 0°C and discharge capacity decreases to over 70% under -20°C.

(4) Good safety performance:When the pressure inside the battery is too large, the one-way safety valve will release gas and heat to make sure battery perform well. When the internal pressure reaches a certain level, the valve will be open immediately which can protect the battery from burning and explosion.

(5) Good cycle life time, the discharge capacity is still over 80% after 3000 cycle times of single cell(80%DOD).

(6) It can fast charging. It could be charged to 80% within 0.5h and charged full with 2-3h.

(7) No pollution during manufacture and usage.

Matters Needing Attention

(1) Please check if spare parts are completed when open the package and read the operation manual carefully.

(2) Do not make the battery Short Circuit,do not over charge and discharge.

(3) Please charge the new battery to full capacity before discharge for the first use.

(4) The battery pack is fixed with plate and strip before delivery, do not disassemble the plate and strip when using

the battery.

(5) Checking the voltage of battery, normally it is 3.2V-3.3V.

(6) Fix BMS for battery pack and protect single cell to avoid over charge and over-discharge.

(7) Rivet or screw is used for battery connector.

(8) Please use copper part to connect battery packs and fix with hydraulic pressure plier. We could also provide the relevant connection which fixed with screws.

(9) The charger used should be approved by our company in order to match with our lithium batteries.

(10) It will shorten battery cycle lifetime and damage battery due to overcharge and over-discharge if not do according

to the above. It won’t be within our company warranty.


Requirement for safety assurance


For the sake of safety assurance, please discuss the equipment design, its system and protection circuit of Lithium-ion cell advance. And consult about the high rate current, rapid charge and special application in the same way.
